Access Control Systems


This is just a few Access control Systems available. Please call or email for assistance picking a system that will work for your needs.

CO-100-CY-70-KP-SPA-

The CO-100 is ideal for doorways needing a secure, non-keyed offline solution where a credential system is not in place. Entry is gained with a simple 3-6 digit PIN codes that can be programmed at the lock. CO-100 locks are capable of storing up to 500 unique PIN codes.

Like all electronic access control solutions, CO-100 helps reduce or eliminate the need to issue keys – serving to protect the integrity of the key system. However, key override is a standard feature and CO-100 is offered in all Schlage open or restricted key systems, plus many competitive cylinder types. It can also be ordered in cylindrical or mortise chassis as well as an exit trim compatible with Von Duprin, Falcon and other common brands of exit devices.

Cylindrical Lock

  • 1000 event audit trail log, time-stamped by day, date, time and user
  • 150 scheduled automatic lock/unlock events,etc.
  • 200 user codes: Master, manager, supervisor and basic users. Also one-time service code (3-6 digits)
  • Weatherproof -31˚ to +151˚F (-35˚ to +66˚C)
  • Relay may be programmed to energize on one or more selected events
  • 5AA Battery operated; 80,000 cycles, typ.
  • Indoor/Outdoor keypad designed for convenience
  • Flush mount, single-gang design
  • 120 Users
  • Key press feedback via sounder and yellow LED
  • Built-in assignable sounder
  • Bi-color Red/Green LED indicates relay status
  • Non-volatile memory retains codes even if power is lost
  • 1-6 digit codes; digits can be repeated
  • Door relocks automatically
  • Two lever User Management
  • Master Code must be entered to change user codes
  • Can program door to remain in unlocked position
  • Easy to program at the keypad
  • Functionality: Main relay controls any device requiring on/off switch — such as electric strike, or maglock. Request to exit input trigger
  • Auto adjusting voltage selection
  • Vandal resistant

  • Integrated door control, proximity reader and keypad
  • 2000 users
  • Bi-color LED to indicate operation
  • Works with certain HID 125 kHz formats
  • Fits over a single-gang electrical box
  • Corporate 1000 compatible
  • Glass-mount option included
  • Secured Series & Wiegand compatible
  • UL 294 Listed

  • MiniMax 3 single-door kit
  • MiniMax 3 metal cabinet with lock
  • Max 3 Door control module (DCM)
  • One P-300HA proximity reader
  • AC transformer
  • Built-in 12 VDC 1 amp power supply
  • Programming keypad
  • Hub Manager® Professional software
  • Requires communication module
  • Order number: 0-205601F
